The Littelfuse 460-15-100-SLD Seal Leak Detector Protects pumps from damage.
For a quote please use our contact us form HERE!
 |
| Littelfuse Pump Saver Seal Leak Detector |
The Littelfuse 460-15-100-SLD is a seal-leak detector to sense seal failures on submersible pumps.
A microcontroller-based relay monitors the shaft seal of a submersible pump motor. A resistive probe is installed in the sea cavity. If water leaks into the pump, the resistance measured by the probe decreases. When the resistance drops below the sensitivity set point, the unit will trip and the relay contacts will change state. Output relay logic can be reversed by removing an external jumper. the unit will automatically reset when the fault is cleared.
Control voltage is 120 VAC
2 form A - SPST contacts
8 amps
IP20 / NEMA 1
LED indicators
UL 508
CE IEC 60947
ONE POUND WEIGHT
Din rail or surface mount.
